PowerVerter? APS 2400W Inverter/Charger with
Auto-Transfer Switching and UL Certification
MODEL NUMBER: APS2448UL
Description
Tripp Lite's APS2448UL DC-to-AC inverter with automatic line-to-battery transfer and integrated charging system
serves as an extended run UPS, a standalone power source or an automotive inverter. Supplies 2400 watts of
continuous 120V AC power from any 48V DC bus or battery source. Floating 48VDC ground offers compatibility
with positive or negative grounded DC systems, including 48V telco applications. OverPower? inverter output
feature temporarily provides up to 150% of the continuous output for 1-60 minutes, and DoubleBoost? inverter
output feature delivers up to 200% of the continuous output for up to 10 seconds, providing the extra power
needed to cold start heavy-duty tools and motorized equipment. When hardwire AC input is energized,
commercial power passes through to connected equipment and the battery set is recharged via 3 stage, 15 amp
charging system. In UPS mode, the APS system responds to blackouts and voltage fluctuations with a near
instantaneous automatic transfer to battery-derived AC output. Includes a set of high current DC input terminals
for simple installation (user supplies batteries and cabling - see owner's manual for recommendations). Passes
sine wave utility or generator power during battery charging and UPS line power operation, plus efficient PWM
sine wave AC output in inverter and UPS backup modes. Reliable large transformer design, with frequency
control powers resistive electronic loads or large inductive motors, compressors and other items with high current
needs on start-up. Optional APSRM4 wired remote power switch with full status LEDs provides remote power
inverter on/off switching and continuous status information (APSRM4 sold separate). Supports an unlimited
amount of run-time with any number of user-supplied batteries connected. Highly adaptable to a variety of
applications and site conditions with adjustable charger settings for wet/gel battery types and selectable line to
battery power transfer voltages.
Highlights
48V DC or 120V AC input; 120V
AC output (hardwired)
2400 watts continuous, 3600
watts OverPower? and 4800
watts DoubleBoost? inverter
output
3 stage, 15 amp selectable
wet/dry cell battery charger
Auto Transfer Switching option
for battery backup / UPS
operation
Tested to UL (USA) and CSA
(Canada) standards
High reliability large-transformer
design with protected DC and AC
wiring terminals
Applications
Versatile inverter/charger system
with auto-transfer switching
serves as an automotive inverter
for RVs, conversion vans and
fleet service vehicles; a
standalone alternative power
source for off-grid, alternative
energy or 48V networking
applications and as an
uninterruptible power supply
(UPS) for items compatible with
an 8 millisecond transfer time.
NOTE: For sump pump
applications, Tripp Lite
recommends its "UT" Utility Truck
Inverter/Chargers.
Package Includes
APS2448 Inverter/Charger
Instruction manual with warranty
information
NOTE: To protect against high current draw that may occur during inverter failure, a fuse link rated at 100a
should be positioned no more than 18" from the APS2448UL's battery in the positive line.
Features
APS2448UL serves as an automotive or stationary DC-to-AC inverter with automatic line-to-battery transfer and integrated battery charger
Supports 120V AC output from a 120V AC line power source or 48V DC battery source
1 / 5
